Beacon&Horn
- Explosion-proof product with warning light and horn integrated
- Employing aluminium housing with high durability and high anti-corrosion
- Equipped with protection cage that keeps the globe from being touched from outside
- Suitable for warning at places having the risk of inflammatory explosion like petrochemical plants, crude oil carriers and chemical factories
- Lens color : -R, -A, -G, -B
- Material : Filter-PC, Body-DIECAST Al, Horn housing-SUS316L
- LensTempered explosion proof glass, Protection cage-SUS316L
- Certificate : KOSHA, KR, KIMM, ABS, ATEX, NEPSI, CCS
- Protection class : KIMM - ExdⅡCT6, IP66 NEPSI - ExdⅡCT6, IP66
ATEX - Ⅱ2G Exd IIC T6, IP66
KOSHA - ExdⅡB + H2, IP66 - Ambient temperature range : -40℃≤Tamb≤+60℃
- Ratings : 12VDC, 24VDC, 230VAC
SPECIFICATION
| MODEL | Weight | Built-in sound | dB/m(MAX) | Rated Voltage | ||
| SESA (Bulb Revolving Light type) |
DC | 6.19kg | WS WP WM WA WV |
5 Warning sounds 5 SP Warning sounds 5 Melodies 5 Alarms 3 Voice signals |
118dB 118dB 118dB 115dB 113dB |
DC 12V DC 24V AC 110V AC 220V |
| AC | 6.93kg | |||||
| SESAL (LED Steady / Flashing Light type) |
DC | 6.02kg | ||||
| AC | 6.04kg | |||||
| SESALR (LED Revolving Light type) |
DC | 6.26kg | ||||
| AC | 7.01kg | |||||
| SESAS (Xenon Lamp Strobe Light) |
DC | 6.05kg | ||||
| AC | 6.40kg | |||||
